Productinformatie "Intel NUC BXNUC10I5FNK2 PC/workstation barebone UCFF Zwart i5-10210U BGA 1528 1,6 GHz"
Intel NUC BXNUC10I5FNK2. Type behuizing: UCFF, Type product: Mini PC barebone. Processor socket: BGA 1528. Ondersteunde geheugen types: DDR4-SDRAM, Aantal geheugenslots: 2, Maximum intern geheugen: 64 GB. Ondersteunde types opslag-drives: SSD. Aantal Ethernet LAN (RJ-45)-poorten: 1. Wi-Fi-standaarden: Wi-Fi 6 (802.11ax)
  • UCFF Zwart
  • Type processor Intel i5-10210U 1,6 GHz
  • 2 SO-DIMM Maximum intern geheugen: 64 GB DDR4-SDRAM
  • SSD M.2
  • Intel® UHD Graphics
  • Ethernet LAN Wifi

Specificaties

Overige specificaties

ARK ID: 195507
ARK ID processor: 195436
Aan/uitschakelaar: Ja
Aantal Ethernet LAN (RJ-45)-poorten: 1
Aantal M.2 (M) slots: 1
Aantal SATA-aansluitingen: 2
Aantal USB-aansluitingen: 7
Aantal displays ondersteund: 3
Audio-uitgangskanalen: 7.1 kanalen
Bluetooth: Ja
Breedte: 117 mm
Commodity Classification Automated Tracking System (CCATS): G157815L2
Compatibele besturingssystemen: Windows 11 (64-bit), Windows 10 (64-bit)
Consumer infrared Rx-sensor: Ja
DC voltage input: 19 V
Diepte: 112 mm
DisplayPort versie: 1.2
Ethernet LAN: Ja
Export Control Classification Number (ECCN): 5A992C
Extra headers: CEC, 2x USB2.0, FRONT_PANEL, RGB
Grafische adapter-familie: Intel
Hoogte: 38 mm
Inclusief netsnoer: Ja
Kleur van het product: Zwart
Lanceringsdatum: Q4'19
Processorfamilie: Intel® Core™ i5
Processormodel: i5-10210U
Processor socket: BGA 1528
Soort voeding: External AC adapter
Type processor: Ja
Type product: Mini PC barebone
Wifi: Ja

Processor speciale functies

CPU configuratie (max): 1
Enhanced Intel SpeedStep Technology: Ja
Execute Disable Bit: Ja
Idle States: Ja
Ingebouwde opties beschikbaar: Nee
Intel® 64: Ja
Intel® AES New Instructions (Intel® AES-NI): Ja
Intel® Clear Video-technologie: Ja
Intel® Clear Video HD Technology (Intel® CVT HD): Ja
Intel® Flex Memory Access: Ja
Intel® High Definition Audio (Intel® HD Audio): Ja
Intel® Hyper Threading Technology (Intel® HT Technology): Ja
Intel® Identity Protection Technology (Intel® IPT): Ja
Intel® My WiFi Technology (Intel® MWT): Ja
Intel® OS Guard: Ja
Intel® Optane™ Memory Ready: Ja
Intel® Platform Trust Technology (Intel® PTT): Ja
Intel® Quick Sync Video Technology: Ja
Intel® Rapid Storage Technology: Ja
Intel® Secure Key: Ja
Intel® Stable Image Platform Program (SIPP): Nee
Intel® TSX-NI: Nee
Intel® Trusted Execution Technology: Nee
Intel® Turbo Boost Technology: 2.0
Intel® VT-x with Extended Page Tables (EPT): Ja
Intel® Virtualization Technology (VT-x): Ja
Intel® Virtualization Technology for Directed I/O (VT-d): Ja
Intel® vPro™ Platform Eligibility: Nee
Thermal Monitoring Technologies: Ja

Prestatie

Aantal processorkernen: 4
Compatibele geheugenkaarten: SDXC
Geïntegreerde geheugenkaartlezer: Ja
Inclusief besturingssysteem: Nee
Moederbord form factor: UCFF
Ondersteunt Windows: Windows 11 x64, Windows 10 x64
Processorfabrikant: Intel
Status: Launched
Trusted Platform Module (TPM): Nee
USB-versie: 2.0/3.2 Gen 2 (3.1 Gen 2)
Verwijderbare sleuf voor geheugenkaart: SDXC with UHS-II support
Wifi-standaard: Wi-Fi 6 (802.11ax)

Poorten & interfaces

Aansluiting voor netstroomadapter: Ja
Aantal HDMI-poorten: 1
Aantal Internal USB 2.0 ports: 2
Aantal SATA III connectors: 2
Aantal Thunderbolt 3-poorten: 1
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A: 3
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C: 2
Combo koptelefoon/microfoon port: Ja
Grafische uitvoer: HDMI 2.0b; USB-C (DP1.2)
HDMI versie: 2.0b
M.2-kaartsleuf (opslag): 2242/2280
Wi-Fi-standaarden: Wi-Fi 6 (802.11ax)

Processor

Codenaam processor: Comet Lake
Frequentie van processor: 1,6 GHz
Geheugenbandbreedte ondersteund door de processor ( max): 42,6 GB/s
Maximale turbofrequentie van processor: 4,2 GHz
PCI Express configuraties: 1x4, 2x2, 1x2+2x1, 4x1
PCI Express slots versie: 3.0
Processor aantal threads: 8
Processor cache: 6 MB
Processorgeneratie: Intel® 10de generatie Core™ i5
Processor lithografie: 14 nm
Thermal Design Power (TDP): 25 W

Kenmerken

SSD-vormfactor: M.2

Geheugen

Aantal DIMM sloten: 2
Aantal geheugenslots: 2
ECC: Nee
Geheugen bandbreedte (max): 42,6 GB/s
Geheugen kanaal: Dubbelkanaals
Geheugen slots type: SO-DIMM
Geheugen voltage: 1.2 V
Maximum intern geheugen: 64 GB
Ondersteunde geheugen types: DDR4-SDRAM
Supported memory clock speeds: 2666 MHz

Design

Type behuizing: UCFF

Netwerk

LAN controller: Intel® I219-V
WLAN-controller-model: Intel Wi-Fi 6 AX201

Opslagmedia

Aantal storage drives ondersteund: 1
Ondersteunde types opslag-drives: SSD
Opslagschijf afmetingen ondersteund: M.2

Computersysteem

On-board graphics adapter model: Intel® UHD Graphics

Energie

AC-adapter, uitgangsspanning: 19 V

Grafisch

Ingebouwde grafische adapter: Nee

Logistieke gegevens

Code geharmoniseerd systeem (HS): 84713000

Inhoud van de verpakking

Processor inbegrepen: Intel® Core™ i5-10210U Processor (6M Cache, up to 4.20 GHz)
